We are a professional service provider integrating refrigeration design, cold storage construction, and refrigeration equipment supply. With years of experience in the refrigeration industry, we have a mature design team, a professional construction team, and a high-quality equipment supply chain. We focus on providing customized overall low-temperature cold storage solutions for various enterprises such as food processing, fresh food circulation, warehousing and logistics, and pharmaceutical and chemical industries.

Inquiry

Write a Review

Product Overview

For goods requiring long-term deep-freeze storage, we adopt the mature scientific combined refrigeration mode of air cooler plus duct, add the AI intelligent defrosting function, and match the full-process intelligent monitoring system, which can achieve precise temperature control in the full range of -30~-18℃ to meet the long-term freeze storage needs of different goods. We provide a full-process one-stop service from early on-site survey, accurate heat load calculation, and personalized scheme design, to equipment selection, on-site installation and commissioning, and then to later regular inspection, fault maintenance, and equipment maintenance. We follow up and strictly control the whole process to create a stable, energy-saving, safe and compliant professional low-temperature cold storage environment for customers. With the uniform air supply of air cooler + duct, the efficient defrosting of AI intelligent defrosting, and the all-round protection of intelligent monitoring, we effectively avoid the storage pain points of traditional low-temperature cold storage, further ensure the quality of goods storage, and reduce the enterprise's warehousing loss.

Due to differences in their own characteristics, different types of frozen goods have distinct requirements for storage temperature, defrosting control, ventilation conditions and environmental cleanliness. For example, frozen meat requires stable low temperature to prevent oxidation, frozen fruits and vegetables require uniform air supply to prevent freeze burn, and pharmaceutical cold chain products require precise temperature control to prevent quality degradation. We reject the "one-size-fits-all" standardized design and adhere to the core principles of customization according to needs, precise temperature control, uniform air supply, and intelligent defrosting. Relying on the exclusive refrigeration mode of air cooler plus duct, combined with AI intelligent defrosting and intelligent monitoring system, we carry out personalized scheme design in combination with the customer's site size, goods storage capacity, stacking method and industry compliance requirements. Through scientific equipment layout, optimized duct layout, and debugging of AI defrosting parameters, each cold storage is accurately adapted to the actual use scenario. While strictly ensuring the quality of goods storage and meeting industry compliance standards, we realize the efficient operation of the refrigeration system, reduce the enterprise's energy consumption cost, and extend the service life of equipment, completely solving the core pain points of traditional low-temperature cold storage such as uneven air supply, large local temperature deviation, severe frosting, high goods loss rate and high energy consumption.

8 (13)

7 (16)

key feature

Applicable Storage Scope of -30~-18℃ Low-Temperature Cold Storage

Our low-temperature cold storage can be precisely adjusted and stably controlled within the range of -30~-18℃. The specific storage temperature can be flexibly set according to the characteristics of goods (for example, -18~-22℃ for meat freezing, -25~-30℃ for deep-sea aquatic products, and -18~-20℃ for frozen fruits and vegetables). The temperature fluctuation is strictly controlled within ±1℃, which meets the low-temperature storage standards of food, medicine and other industries; equipped with the refrigeration and air supply mode of air cooler + duct, combined with AI intelligent defrosting function, it effectively avoids frost accumulation in the warehouse, ensures uniform temperature distribution in the warehouse without local hot and cold dead corners, and keeps the internal environment clean and dry. It is widely applicable to the long-term deep-freeze storage of various types of goods, with a storage cycle usually ranging from 3 to 12 months, including:

Other Goods Requiring Deep-Freeze Storage

In addition to the above categories, it is also suitable for various goods that need deep-freeze storage at -30~-18℃, including: frozen pet food (pet frozen dry food, frozen meat strips, etc.), cosmetic raw materials (some oils and extracts that need low-temperature storage, etc.), electronic components (precision accessories with special requirements for low-temperature environment), chemical raw materials (some chemical products that need low-temperature storage to prevent civilization or deterioration, etc.). We can customize exclusive storage schemes according to the storage characteristics of different goods and industry compliance requirements, and match suitable air supply, temperature control and AI defrosting parameters, fully meeting the deep-freeze storage needs of multiple industries and categories, and ensuring the safety and quality stability of goods storage.

Pharmaceutical and Biological Products

It is suitable for some pharmaceutical and biological products that need deep-freeze storage. The low-temperature environment of -30~-18℃ can effectively maintain the activity of the products, prevent them from failing and deteriorating, and is suitable for the storage needs of pharmaceutical enterprises and scientific research institutions. Specifically, it includes: some biological agents, vaccines (categories requiring deep freezing), medical reagents, stem cells, biological samples, etc. Such goods have extremely high requirements on temperature stability and environmental cleanliness. We can accurately control the temperature of the cold storage within the specified range (such as -20~-25℃), with temperature fluctuation controlled within ±0.5℃. Equipped with the uniform air supply mode of air cooler + duct, it ensures uniform temperature in the warehouse. The AI intelligent defrosting function can avoid temperature fluctuation during defrosting, and at the same time, add a clean filtration device in the warehouse to keep the internal environment clean, meet the strict compliance requirements of the pharmaceutical industry, and ensure the storage safety and quality stability of pharmaceutical and biological products.

Frozen Food and Prepared Dishes

It is suitable for various finished and semi-finished frozen foods and prepared dishes that need long-term freeze storage. Deep freezing can effectively inhibit food deterioration, retain the flavor, taste and quality of food, and is suitable for the bulk storage and turnover needs of food processing enterprises, catering enterprises and fresh supermarkets. Specifically, it includes: frozen rice and flour products (quick-frozen dumplings, quick-frozen glutinous rice balls, quick-frozen noodles, frozen steamed buns, etc.), frozen conditioned food (frozen fried chicken, frozen French fries, frozen steak, etc.), prepared dishes (frozen home-cooked dishes, frozen hot pot ingredients, frozen bent, etc.), frozen cooked food (frozen braised food, frozen sauce meat, etc.). In the low-temperature environment of -30~-18℃, the storage cycle of such food can be extended to 3~6 months, ensuring that the taste and flavor of food are not lost; the uniform air supply mode of air cooler + duct can avoid uneven frosting and freeze burn on the food surface, and the AI intelligent defrosting function can ensure the continuous and efficient operation of the refrigeration system, avoid temperature fluctuation caused by frosting, ensure food storage safety, and meet the compliant storage requirements of the food industry.

Low-Temperature Cold Storage Solution (-30~-18℃) — Air Cooler + Duct Mode with AI Intelligent Defrosting & Intelligent Monitoring System 14

Frozen Aquatic Products and Seafood Products

It is suitable for various aquatic products and seafood that need deep-freeze storage. Deep freezing can effectively inhibit the activity of enzymes in aquatic products, prevent meat softening and corruption, retain the tender taste and nutrition of seafood, avoid seafood oxidation and discoloration and peculiar smell, and is suitable for scenarios such as ocean fishing, bulk storage and cross-regional distribution. Specifically, it includes: frozen marine fish (cod, salmon, tuna, hair tail, yellow croak, etc.), frozen freshwater fish (carp, grass carp, crucial carp, etc.), frozen shrimp (prawns, Chinese shrimp, crayfish, etc.), frozen shellfish (scallops, oysters, clams, etc.), and various processed aquatic products (fish balls, fish steaks, shrimp meat, squid rings, etc.). For deep-sea aquatic products (such as tuna and cod), the temperature can be set at -25~-30℃ to maximize the retention of their tender taste and nutritional components; the uniform air supply mode of air cooler + duct can avoid uneven frosting and local freeze burn on the surface of aquatic products, and the AI intelligent defrosting function can effectively solve the problem of reduced refrigeration efficiency caused by too fast and too thick frosting of air coolers in low-temperature environments, ensure stable temperature in the warehouse, extend the storage cycle of aquatic products to 3~10 months, and reduce the loss rate during storage.

Low-Temperature Cold Storage Solution (-30~-18℃) — Air Cooler + Duct Mode with AI Intelligent Defrosting & Intelligent Monitoring System 15

Frozen Meat and Poultry Products

This type of goods is the core applicable category of -30~-18℃ low-temperature cold storage. Deep freezing can quickly lock the activity of meat cells, avoid cell rupture, retain the tender taste of meat and nutritional components such as protein and minerals, effectively prevent meat oxidation, deterioration and bacterial growth, and is suitable for long-term storage and long-distance transportation. Specifically, it includes: frozen livestock meat such as pork, beef, mutton and donkey meat (including cut meat and whole meat), frozen poultry meat such as chicken, duck and goose (including dressed poultry and cut poultry meat), and various meat products (such as frozen sausages, ham, bacon, meatballs, conditioned meat skewers, etc.). In the low-temperature environment of -30~-18℃, the storage cycle of meat can be extended to 6~12 months, and the taste and nutritional components of meat after thawing are basically not affected; the uniform air supply mode of air cooler + duct can avoid freeze burn and uneven frosting on the meat surface, and the AI intelligent defrosting function can accurately control the defrosting time and intensity, avoiding the decline of meat quality caused by excessive temperature fluctuation in the warehouse during defrosting. Combined with the built-in ventilation system of the cold storage, it can timely discharge the peculiar smell in the warehouse, keep the air in the warehouse circulating and the environment clean, further ensure the safety of meat storage, and comply with the food safety production standards.

Low-Temperature Cold Storage Solution (-30~-18℃) — Air Cooler + Duct Mode with AI Intelligent Defrosting & Intelligent Monitoring System 16

Frozen Fruits and Vegetables

It is suitable for various frozen fruits and vegetables that have undergone pare-treatment (cleaning, cutting, pre-Columbian). Deep freezing can quickly lock the moisture and nutritional components of fruits and vegetables, delay the oxidation and decay of fruits and vegetables, avoid freeze burn, browning and other problems of fruits and vegetables, and is suitable for scenarios such as bulk storage and off-peak sales of fruit and vegetable planting bases, and raw material storage of food processing enterprises. Specifically, it includes: frozen leafy vegetables (spinach, lettuce, Chinese cabbage, etc.), frozen root and tuber vegetables (carrots, potatoes, onions, etc.), frozen solanaceous fruits (tomatoes, cucumbers, eggplants, etc.), frozen melons and fruits (strawberries, blueberries, mangoes, durians, etc.), and various processed frozen fruit and vegetable products (frozen fruit and vegetable diced, fruit and vegetable strips, fruit and vegetable puree, etc.). In the low-temperature environment of -30~-18℃, the storage cycle of frozen fruits and vegetables can be extended to 6~12 months, and part of the taste and nutrition of fruits and vegetables can still be retained after thawing; the uniform air supply mode of air cooler + duct can ensure that each batch of frozen fruits and vegetables is in a stable low-temperature environment, avoiding thawing and deterioration caused by local high temperature, and the AI intelligent defrosting function can avoid condensed water generated during defrosting from contacting fruits and vegetables, preventing fruits and vegetables from getting damp and caking, further ensuring the quality of frozen fruits and vegetables and reducing storage loss.

Core Configuration — Air Cooler + Duct Mode with AI Intelligent Defrosting Function

Our low-temperature cold storage (-30~-18℃) adopts the mature and reliable air cooler + duct refrigeration mode, and adds the AI intelligent defrosting function at the same time. The three work together to ensure uniform air supply and efficient refrigeration, and completely solve the frosting problem of low-temperature cold storage, adapting to various scenarios of -30~-18℃ deep-freeze storage. The specific characteristics are as follows:

• Uniform Air Supply Without Dead Corners

In the scheme design stage, we will conduct professional air distribution calculation according to the length, width and height of the cold storage, the height and layout of goods stacking, and scientifically layout the installation position of the air cooler and the direction of the duct. After being cooled by the air cooler, the cold air is uniformly delivered to all areas of the cold storage along the preset duct, and then uniformly diffused through the air outlets reserved in the duct to form a stable circulating air flow, effectively avoiding local temperature deviation and ensuring that the temperature of every corner in the cold storage is stable within the set range (±1℃). This air supply mode completely eliminates the problems of "cold top and hot bottom" and "high temperature in corners" in traditional refrigeration methods, and is especially suitable for the storage of bulk and neatly stacked goods, ensuring that the goods at the bottom, top and corners are in the same stable low-temperature environment, and avoiding goods freeze burn, deterioration or quality decline caused by uneven air supply.

• Efficient Refrigeration and Energy Saving

The air cooler we select adopts high-efficiency copper tube and aluminum fin evaporator, which has high heat exchange efficiency and can quickly cool the air in the warehouse to the range of -30~-18℃, effectively shortening the cold storage start-up time (under no-load condition, it only takes 6~8 hours to cool from normal temperature to -18℃, and 10~12 hours to cool to -30℃); combined with reasonable duct design, it can reduce cold air short-circuit back flow, allow cold air to fully exchange heat with the air in the warehouse, improve refrigeration efficiency, and reduce the operation load of the refrigeration unit, thus reducing the enterprise's energy consumption cost. Compared with the traditional single refrigeration mode, this combined mode has significant energy-saving effect, with energy consumption reduced by 15%~25%, suitable for long-term continuous operation, able to meet the long-term freeze storage needs of large quantities of goods, and help enterprises reduce operating costs.

• AI Intelligent Defrosting, Efficient and Convenient

Aiming at the pain point that air coolers are prone to frosting and affect refrigeration efficiency in the low-temperature environment of -30~-18℃, we add the AI intelligent defrosting function. Different from traditional manual defrosting and timed defrosting, the AI system can real-time monitor the frosting thickness of the air cooler and the temperature change in the warehouse, intelligently judge the defrosting time and duration, and accurately control the defrosting process. It can not only completely remove the frost on the surface of the air cooler, avoid the reduction of refrigeration efficiency and increase of energy consumption caused by excessive frosting, but also avoid excessive temperature fluctuation in the warehouse caused by too long defrosting time or improper timing, maximizing the protection of goods quality; at the same time, AI defrosting can be completed automatically without manual operation, reducing labor costs, and the refrigeration system can be automatically adjusted during defrosting to ensure that the temperature in the warehouse is stable within a reasonable range, further improving the operation efficiency of the cold storage.

• Stable and Reliable Operation, Convenient Maintenance

The air cooler we select has a solid structure, corrosion resistance and low temperature resistance (suitable for low-temperature working conditions below -30℃), and is not prone to frosting blockage, component damage and other problems; matched with high-quality galvanized steel sheet duct, it has good sealing performance and is not easy to deform, which can effectively reduce cold air leakage and ensure stable refrigeration effect. The AI intelligent defrosting system is linked with the refrigeration system, which can automatically detect the operation status of the equipment, and timely find defrosting abnormalities, equipment failures and other problems, facilitating staff to deal with them in a timely manner; the later maintenance of the equipment is convenient, the air cooler can be regularly cleaned and inspected, the duct can be regularly cleaned, and the AI defrosting parameters can be remotely debugged, reducing the incidence of equipment failure, ensuring the long-term stable operation of the cold storage, and guaranteeing the safety of goods storage.

• Ensure Clean Storage Environment

The air cooler we select is equipped with a high-efficiency filter device, which has certain dust removal and demystification functions, can filter dust and impurities in the air, and reduce the generation of condensed water in the warehouse; matched with air supply through the duct with good sealing performance, it can effectively reduce external dust and moisture entering the warehouse, avoid the accumulation of dust and condensed water in the warehouse, and keep the storage environment clean and dry. The AI intelligent defrosting function can avoid condensed water residue during defrosting, further keeping the warehouse dry. This clean environment is especially suitable for food, medical and other goods with high requirements on storage environment, which can avoid the quality degradation and pollution of goods caused by dampness and dust, and ensure that the goods storage meets the industry compliance standards.

Intelligent Monitoring System — All-Round Protection for Low-Temperature Storage Safety

To fully ensure the safety of goods stored at -30~-18℃ and avoid goods loss caused by temperature fluctuation, abnormal frosting and equipment failure, we standard-equip an intelligent monitoring system for each set of low-temperature cold storage. The system adopts industrial-grade monitoring equipment, which is linked with the AI intelligent defrosting system and the refrigeration system to realize 24-hour uninterrupted intelligent management, covering real-time monitoring of multiple parameters such as temperature, humidity, frosting status and equipment operation status, ensuring the stability of the internal environment of the warehouse. The specific functions are as follows:

• Multi-Parameter Real-Time Monitoring

The platform is equipped with high-precision temperature and humidity sensors, which can accurately collect temperature and humidity data in different areas of the warehouse (such as the top, middle, bottom and corners of the warehouse) with a sampling frequency of once every 10 minutes. The data is stable and reliable with an error of no more than ±0.1℃, real-time feedback of the storage environment status; at the same time, it can real-time monitor the frosting thickness and defrosting status of the air cooler, as well as the operation parameters of the refrigeration unit and duct system, intuitively display the temperature difference in each area of the warehouse and the defrosting progress, facilitating staff to find and adjust in time to ensure that the internal environment of the warehouse meets the goods storage requirements.

• Data Traceability

The data curves of temperature, humidity, frosting status, equipment operation parameters, etc. are automatically recorded with a storage cycle of more than 1 year. Historical data can be queried and exported at any time (supporting Excel, PDF and other formats), which can trace the environmental parameters and equipment operation status of the whole process of goods storage, meet the compliance review requirements of food safety production, medical storage and other industries, and facilitate enterprises to keep relevant records and cope with various inspections and acceptances.

• Remote Convenient Management

It supports remote viewing through dual terminals of computer management platform and mobile APP. Staff do not need on-site duty, and can grasp the cold storage operation status, refrigeration unit working condition, duct air supply effect, AI defrosting progress and internal temperature and humidity data of the warehouse anytime and anywhere. At the same time, they can set temperature and humidity thresholds, adjust AI defrosting parameters and refrigeration system operation parameters through the remote terminal, greatly improving management efficiency and reducing labor costs.

• Abnormal Automatic Alarm

When the temperature and humidity in the warehouse exceed the preset range (such as the meat storage temperature exceeds -18~-22℃), or the air cooler has abnormal frosting, the AI defrosting system fails, or the refrigeration equipment and duct system fail (such as air cooler shutdown, duct leakage, refrigeration unit failure), the system will immediately send an alarm signal to the staff through multiple methods such as APP push, SMS reminder and phone call, reminding the staff to deal with it in the first time, minimizing goods loss and ensuring the safety of goods storage.

• Adaptation to Centralized Management

It supports centralized management of multiple cold storage and multiple regions. The operation data of multiple low-temperature cold storage can be uniformly connected to the management platform. Staff can monitor the operation status, temperature and humidity data, AI defrosting status and equipment working conditions of multiple sets of low-temperature cold storage at the same time, and can group manage and set parameters for different cold storage, with convenient operation and efficient management, truly realizing unattended and safe control, and adapting to the centralized management needs of large warehousing and logistics enterprises, multi-store fresh food enterprises and pharmaceutical enterprises.

We not only provide professional -30~-18℃ low-temperature cold storage, equipped with the uniform air supply refrigeration mode of air cooler + duct, combined with AI intelligent defrosting and intelligent monitoring system, but also provide full-life-cycle services from design to delivery, and from use to maintenance, adhering to the principles of authenticity, compliance and reliability throughout the process, without exaggerating advantages or fabricating parameters.

With mature refrigeration technology, stable and reliable equipment configuration (including high-efficiency air cooler, high-quality duct system, energy-saving refrigeration unit, AI intelligent defrosting system, industrial-grade monitoring system), rigorous construction standards (strictly following the low-temperature cold storage construction industry specifications, focusing on the control of thermal insulation, sealing, refrigeration effect and defrosting performance) and perfect after-sales system (7×24-hour fault response, regular inspection and maintenance, lifelong equipment maintenance guidance), we escort the deep-freeze storage and quality of your goods. Whether it is frozen meat, aquatic seafood, frozen food or pharmaceutical products, we can combine your actual needs to provide precisely adapted solutions, solve your warehousing pain points, reduce operating costs, and become your trusted one-stop refrigeration solution partner.
